Haas EC-400PP 6 Pallet Horizontal Machining Center (2023)
Have one to sell?
ConditionUsed
1 available
Haas EC-400PP 6 Pallet Horizontal Machining Center (2023)
Haas EC-400PP 6 Pallet Horizontal Machining Center (2023)
Model: EC-400PP (Pallet Pool)
DOM: November 2023 (Installed 2024)
Electrics: 220 Volt, 3 Phase, 50-60 Cycle, 40 Amp FLA
Main Motor: 30 HP
Hours:
...Cycle Time: 4,181
...Power On: 11,128
...Servo Time: 5,878
...Feed Time: 3,349
...Main Spindle, Total Usage: 4,259
Features and Specifications:
...CNC Control: Haas w/ Pendant
...6-Station Pool + 1 Load Station
...Pallet Size: 15.75” x 15.75”
...Pallet Load Max.: 880 lbs.
...Spindle Specs:
......CT40 Taper
......15,000 RPM
......Inline Direct Drive
......Thru Spindle Coolant
...Travels:
......X-Axis: 22"
......Y-Axis: 25"
......Z-Axis: 22"
...Cutting Feedrates:
......Cutting: 500 IPM
......Rapid (X,Y,Z): 1,000 IPM
...Tool Changer (ATC): 100 Slots
...Auger
...Rigid Tapping
...Full 4th-Axis Indexing System
...WIPS Probing
...Complete Coolant System
...Hennig Chip Conveyor
...Accessories:
......5 Pallets
......Haas Auxiliary Coolant Filtration
EC400 Equipment Dimensions (approx.): 176” x 92" x 101"
EC400 Equipment Weight (approx.): 17,520 lbs.
Pallet Pool Dimensions (approx.): 108” x 78” x 78”
Haas EC-400PP 6 Pallet Horizontal Machining Center (2023)
Imperial
| size | 16" x 16" |
| X | 20" |
| Y | 20" |
| Z | 20" |
| Power | 20 hp |
| RPM | 8,000 RPM |
| # ATC | 70 |
| Taper | 40 |
| Pallet-W | 15.75" |
| Pallet-L | 15.75" |
| # Axis | 4 |
Haas EC-400PP 6 Pallet Horizontal Machining Center (2023)
Model: EC-400PP (Pallet Pool)
DOM: November 2023 (Installed 2024)
Electrics: 220 Volt, 3 Phase, 50-60 Cycle, 40 Amp FLA
Main Motor: 30 HP
Hours:
...Cycle Time: 4,181
...Power On: 11,128
...Servo Time: 5,878
...Feed Time: 3,349
...Main Spindle, Total Usage: 4,259
Features and Specifications:
...CNC Control: Haas w/ Pendant
...6-Station Pool + 1 Load Station
...Pallet Size: 15.75” x 15.75”
...Pallet Load Max.: 880 lbs.
...Spindle Specs:
......CT40 Taper
......15,000 RPM
......Inline Direct Drive
......Thru Spindle Coolant
...Travels:
......X-Axis: 22"
......Y-Axis: 25"
......Z-Axis: 22"
...Cutting Feedrates:
......Cutting: 500 IPM
......Rapid (X,Y,Z): 1,000 IPM
...Tool Changer (ATC): 100 Slots
...Auger
...Rigid Tapping
...Full 4th-Axis Indexing System
...WIPS Probing
...Complete Coolant System
...Hennig Chip Conveyor
...Accessories:
......5 Pallets
......Haas Auxiliary Coolant Filtration
EC400 Equipment Dimensions (approx.): 176” x 92" x 101"
EC400 Equipment Weight (approx.): 17,520 lbs.
Pallet Pool Dimensions (approx.): 108” x 78” x 78”
