Kiwa KH-4500 CNC 4 Axis Horizontal Machining Center (2020)

Kiwa KH-4500 4 Axis CNC Horizontal Machining Center (2020)

• X-Axis Travel: 27.6 in (700 mm)
• Y-Axis Travel: 29.1 in (740 mm)
• Z-Axis Travel: 26.8 in (680 mm)
• Rapid Traverse Rate: 3,149 in/min (80 m/min) on X, Y, and Z axes
Pallet Specifications
• Pallet Size: 15.7 x 15.7 in (400 x 400 mm)
• Max Load Capacity: 1,100 lbs (500 kg)
• Pallet Change Time: ~7.6 seconds
• Pallet System: Field-expandable Automatic Pallet Changer (APC) supporting pallet pools/FMS configurations (e.g., 6 to 8 stations)
Spindle
• Spindle Power: 50 HP (37.5 kW)
• Standard Speed: 15,000 RPM (optional 12,000 or 20,000 RPM)
• Spindle Taper: CAT 40
Tool Changer (ATC)
• Standard Capacity: 120
• Max Tool Weight: 17.6 lbs (8 kg)
• Chip-to-Chip Time: ~2.8 seconds
Control & Dimensions
• CNC Control: FANUC 31i-B / 31i-B Plus
• Machine Size: Approximately 100 in wide x 178.7 in long x 101.7 in high
