Doosan VC-510 Dual Pallet Vertical Machining Center (2021)
Have one to sell?
ConditionUsed
1 available
Doosan VC-510 Dual Pallet Vertical Machining Center (2021)
Doosan VC-510 Dual Pallet Vertical Machining Center (2021)
Technical Specifications
X-Axis Travel: 762 mm (30 inches)
Y-Axis Travel: 516 mm (20.3 inches)
Z-Axis Travel: 570 mm (22.4 inches)
Max Spindle Speed: 10,000 RPM
Spindle Power: 18.5 kW / 25 Hp
Pallet Size: 860 x 570 mm (33.8 x 22 inches)
Max Pallet Load: 350 kg (770 lbs)
Tool Magazine Capacity: 30 stations
Machine Weight: 9,200 kg (20,283 lbs)
Doosan VC-510 Dual Pallet Vertical Machining Center (2021)
Imperial
| X Travel | 30" |
| Y Travel | 20.315" |
| Z Travel | 22.441" |
| RPM | 10,000 RPM |
| # ATC | 30 |
| Taper | BT-40 |
| Table-W | 22.441" |
| Table-L | 33.858" |
| # Axis | 3 |
Doosan VC-510 Dual Pallet Vertical Machining Center (2021)
Technical Specifications
X-Axis Travel: 762 mm (30 inches)
Y-Axis Travel: 516 mm (20.3 inches)
Z-Axis Travel: 570 mm (22.4 inches)
Max Spindle Speed: 10,000 RPM
Spindle Power: 18.5 kW / 25 Hp
Pallet Size: 860 x 570 mm (33.8 x 22 inches)
Max Pallet Load: 350 kg (770 lbs)
Tool Magazine Capacity: 30 stations
Machine Weight: 9,200 kg (20,283 lbs)
