Southwestern Industries Trak TRL1840SX CNC Lathe (2006)
Have one to sell?
ConditionUsed
1 available
SLX Control
Southwestern Industries Trak TRL1840SX CNC Lathe (2006)
Swing Over Ways: 18.5"
Swing Over Cross Slide: 9.0"
Max Center Distance: 40.2"
Center Height: 9.0"
Cross Slide Travel: 9.0"
Hole Through Spindle: 2.36"
Spindle Nose: D1-6 Camlock
Spindle Speeds: Programmable Variable in 3 Ranges 50-270 / 150-850 / 450 - 2500 RPM
Tailstock Quill Travel: 6.3" Manual
Tailstock Quill Diameter: 2.95"
Tailstock Quill Taper: #5MT
Spindle Drive: 10 HP
SLX Control, 3 Jaw Chuck
SLX Control
Imperial
| size | 10" Chuck |
| Swing | 18.5" |
| Machining Length | 40.25" |
| # Axis | 2 |
| Chuck Size | 10" |
| Turning Dia | 9" |
| Tailstock | Yes |
| Live Tooling | No |
| Sub Spindle | No |
Southwestern Industries Trak TRL1840SX CNC Lathe (2006)
Swing Over Ways: 18.5"
Swing Over Cross Slide: 9.0"
Max Center Distance: 40.2"
Center Height: 9.0"
Cross Slide Travel: 9.0"
Hole Through Spindle: 2.36"
Spindle Nose: D1-6 Camlock
Spindle Speeds: Programmable Variable in 3 Ranges 50-270 / 150-850 / 450 - 2500 RPM
Tailstock Quill Travel: 6.3" Manual
Tailstock Quill Diameter: 2.95"
Tailstock Quill Taper: #5MT
Spindle Drive: 10 HP
SLX Control, 3 Jaw Chuck
