| size | 30" x 16" x 20" | 30" x 16" x 20" |
| X Travel | 30" | 762 mm |
| Y Travel | 16" | 406.4 mm |
| Z Travel | 20" | 508 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 30 | 30 |
| Taper | 40 | 40 |
| Table-W | 14" | 355.6 mm |
| Table-L | 36" | 914.4 mm |
Haas Nextgen Control
15,000 Rpm Spindle (Cat40)
Through-Spindle Coolant (300 Psi)
Renishaw Wireless Intuitive Probing System (WIPS)
4th Axis Drive & Wiring (Rotary Table Not Included)
Side-Mount Tool Changer (30 Atc)
Auxiliary Coolant Filtration System
Programmable Coolant
Window Air Blast
Chip Auger
Auto Door
Visual Part Programming System (Vps Editing)
Coordinate Rotation & Scaling
Media Display M-Code (M130)
High-Speed Machining
Spindle Orientation
Rigid Tapping
Macros
Ethernet
Usb Port
1gb Memory
Wifi Connection
Haasconnect: Remote Monitoring
Cutting Time – 2,309 Hours
Machine Cut Primarily Aluminum
