Travel Capacity:
X Axis (Horizontal): 39.4"
Y Axis (In/Out): 19.68"
Z Axis (Vertical): 30"
5th Axis Tilt: 120° range (+/- 60°)
Table and Workpiece:
Table Size: 19.68" x 59.09" with 5 T-slots
Cylinder Head Capacity: Up to 43" in length
Weight Capacity: 1,543 lbs
Spindle Performance:
Taper: CAT40
Speed: Standard 0 to 20,000 RPM
Motor: 43 HP continuous
Torque: 60 ft-lbs (80 Nm) at 1000 RPM
Operation Speeds:
Rapid Travel: 540 ipm
Feed Rate: 0–100 ipm
Machine Weight: Approximately 13,277 lbs
