Spindle: 12 HP (horsepower) HSD (Italian) Electrospindle, air-cooled, with ceramic bearings.
Spindle Speed: 5,000 to 24,000 RPM (revolutions per minute).
Automatic Tool Changer: 8-position ISO 30 tool rack system.
Frame: Heavy-duty, one-piece, all-welded structural steel frame, designed to minimize vibration.
Drive System: Helical rack-and-pinion drives on the X and Y axes, and a precision-ground ball screw on the Z axis.
Vacuum Table: Multi-zone phenolic universal grid table with T-slots (typically 6 zones).
Power Requirement: Typically 208-230V, 3-phase power supply is required, with a constant minimum air pressure of 85 psi (pounds per square inch)
