Valve Seat Diameter: .550" - 4.724" (14mm - 120mm)
Maximum Cylinder Head Length (with 360° rollover fixture): 44” (1118mm)
Maximum Cylinder Head Length (with diesel fixture): 50” (1270mm)
Spindle Diameter: 3.150” (80mm)
Maximum Spindle Stroke: 8” (203mm)
Maximum Tilt (either side of zero): 5 degrees
Distance from Table to Spindle: 9.5” (495mm)
Spindle Speed: 40 to 400 rpm
Electrical Requirements: 208/220 volt, single phase, 15 amp
Air Requirements: 90/100 psi 6 Bar
Spindle Motor: 1 HP/.75 kW
Machine Dimensions: 53” wide x 32” deep x 74” high (1346 x 813 x 1880mm)
Working Dimensions: 84” wide x 42” deep x 80” high (213m x 1067 x 2032mm)
Shipping Dimensions: 59” wide x 39” deep x 83” high (1499 x 991 x 2108mm)
Shipping Weight: 2700 lbs (1227 kg)
Paint Color Code: RAL9002 (Grey White)
