| X | 145" | 3,683 mm |
| Y | 87.5" | 2,222.5 mm |
| Z | 22" | 558.8 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 10,000 RPM | 10,000 RPM |
| # ATC | 31 | 31 |
| Taper | 40 | 40 |
- Internal High-Voltage Isolated Transformer for 380-480V operation.
- 10,000-rpm Spindle, 40 taper, 30 hp (22.4 kW) vector drive, inline direct-drive.
- Wireless Intuitive Probing System
- Haas Visual Programming System
- Macros
- Spindle Orientation
- Coordinate Rotation
- Scaling
- CNC Control Cabinet Coole
- Coolant System; includes 95-gallon (360 liter) coolant tank and 3/4 hp (0.6 kW) pump
- Through-Spindle Coolant, 1000 psi (69 bar)
- High-Speed Machining; allows faster feedrates and more complex toolpaths, without hesitation or starving the machine.
- Automatic Air Gun
