Table:
Table Dimensions 59 X 20”
Width of T Slots 5 - .63 x 3.94”
Maximum Weight Capacity on Table 1540 lbs
Travel:
X Axis Travel (Horizontal) - 40.5”
Y Axis Travel (In/Out) - 20.5”
Z Axis Travel (Vertical) - 30.5”
Spindle Nose to Table - 10 - 40”
Spindle:
Spindle Taper - Cat 40
Spindle Rotation Speed - 0 to 5000 RPM
Performance:
Rapid Travel X & Y - 400 IPM
Rapid Travel Z - 400 IPM
Motors AC Brushless Servo Motors with BISS Encoders
Spindle Motor - 6 HP,
Tool Changer:
Number of Tools - 24
Maximum Weight of Tool - 15.5lbs
Maximum Diameter of Tool - 10”
Tool Changing Time - 2 seconds
Overall Specifications:
Coolant Capacity - 30 gallons
- Auger
- Water pump
- Rottler Cam/4c software
- Rottler block program
- Many different block programs saved
- Dart SBC lightening program
- Renishaw probe setup
- SBC pucks (others can be negotiated)
- Fly cutter
- Boring head
