Jones & Shipman Suprema Easy 650 Universal I.D./O.D. Cylindrical Grinder (2010)
Have one to sell?
ConditionUsed
1 available
Internal Grinding Spindle, (2) OD Spindles, (1) ID Spindle, Full B Axis Grinding Head
JONES & SHIPMAN SUPREMA EASY 650 UNIVERSAL I.D./O.D. CYLINDRICAL GRINDER (2010)
Table:
Swing:....................................... 12.5"
Distance Between Centers:.................... 25.5"
Table Travel ................................ 29.5"
Max. Traverse Speed ......................... 472" IPM
HPG Increments .............................. 0.00005", 0.0005", or 0.005"
Table Swivel ................................ 18 Deg. CCW, 16 Deg. CW
Wheelhead:
Total Infeed Travel:......................... 10.236""
Max. Speed .................................. 236" IPM
Minimum Programmable Increment .............. 0.00005"
HPG Increments .............................. 0.00005", 0.0005", or 0.005"
Swivel Range ................................ 190 Degrees CW
45 Deg. CCW
External Grinding Wheels:
Grinding Wheel Size, L.H. Standard:.......... 14" x 2"W x 5"B
R.H Standard: .......... 12" x 1"W x 5"B
Spindle Speeds (3):.......................... 1773, 2069 & 2400 RPM
Motor Power: ................................ 5.5 H.P.
Headstock:
Swivel:...................................... 15 Degrees CW
90 Deg. CCW
Speed, Infinitely Variable:.................. 30 to 450 RPM
Centers, Standard/Reduced ................... #5 MT/#3 MT
Approximate Weight: ......................... 11,000 Lbs.
Internal grinding wheel attachment (17,000 RPM, WILL CONFIRM)
"GE Fanuc Quickpanel" Microprocessor Control - Touch Control Panel
Table and wheelhead driven by AC digital servo motors,
preloaded ballscrews & rotary encoders.
is from a unique, operator compatible, touch key panel,
that's easy to use and, because of faster set ups,
enables a higher level of grinding performance."
Three Wheelhead Design, L.H. Standard, R.H. Standard
and Swing Around Internal Grinding, complete
with internal grinding spindle.
Variable Speed Drives for the ID & OD
