Eagle Model iNspire 2040 F20.0 20,000 Watt Fiber Laser Cutting System (2021)

Eagle Model iNspire 2040 F20.0 Series 20,000 Watt Fiber Laser Cutting System (2021)

170 Beam On Hours as of 4/9/2025
Cutting Speed: Max. 5,906″ /Min.
Positioning: 13,780″ /Min.
Accelerations: 6G
Laser Sources: 1 – 15 kW
Working Area:
X-Axis: 160″
Y-Axis: 80″
Z-Axis: 4″
Max. Sheet Weight: 3,086 lbs.
Max. Speeds:
Parallel to X, Y, Z-Axis: 9,843″ /Min.
Simultaneously: 13,780″ /Min.
Axis Parameters:
Repeatability: .118″
Cutting Precision: .196″
Accelerations: 6G
Min. Programmable: .0393″
Standard Features:

Fiber laser source
Linear motors on all axes
Polymer Granite Base
Carbon Fiber Bridge
eVa Ultrahigh Power Cutting Head
eSoft Drawing, Nesting, Quoting Software
Collision Sensing and Breakaway Head
Sheet Position Recognition
Dust Collector System
CutEye-Rapid Edge Detection
Traverse Conveyor
Options Included::
CraneMaster Auto Load/Unload, 10 Mono Towers
Automatic 36 Bay Nozzle Changer, includes Eagle AC

Dimensions: 441″ x 161″ x 120″ H
Weight: approx. 47,620 lbs.
