Trumpf Trulaser 2030 4kw Fiber Laser (2016)

Description

Easy entry to laser cutting // High productivity at low investment and operating costs // Intuitive operation reduces amount of training needed

TruLaser 2030 fiber is available with two, three or four kilowatts of laser power. It displays its strengths especially in sheet thicknesses from one to twelve millimeters, where it cuts very fast. It also processes thicker sheets. Thanks to the robust TruDisk solid-state laser, the TruLaser 2030 fiber can cut highly reflective materials such as copper even using nitrogen.

All materials and sheet thicknesses can be processed with the same cutting unit. This saves setup time, as there is no need to change the lens and cutting head. Along with other parameters, the focal position of the laser also adjusts automatically to the respective material. The cutting head’s collision protection and an automatic nozzle changer with space for eight nozzles reduce setup times even further.

Depending on the capacity utilization and the degree of automation wanted, the machine is available with a pallet for manual loading and unloading, a pallet changer or LiftMaster Shuttle. The retrofittable LiftMaster Shuttle makes it possible to load and unload the machine on a fully automated basis. Available in many different installation versions, the TruLaser 2030 fiber adapts perfectly to the material flows and space conditions of the manufacturing operations at hand.
