Hurco HTX500 Horizontal Machining Center (2006)

Hurco HTX500 Horizontal Machining Center (2006)

Pallet Size
19.6" x 19.6" (2) Pallet
Travels
24" x 24" x 24"
Maximum Table Load
1,100 lbs per pallet
Spindle Nose to Table
6.1” to 30.12”
B Axis Motion
360 Degrees
Coolant Capacity
153 Gallons
Pallet Top (24) - M16 Hole Matrix on
3.94” Centers
Spindle
Spindle Taper
CAT 40
Spindle Speed
10,000 RPM
Spindle Motor Horsepower
(1 min.) 24 HP
Spindle Motor Torque
(1 min.) 175 Ft. lbs 720 RPM
Rapid Traverse Rate
X,Y and Z 1,260 ipm
Cutting Feed Rate
600 ipm
Least Command Increment
0.0001”
B Axis Feedrate
33.3 RPM
B Axis Clamping Force
(4 cone clamp system) 10,000 lbs
B Axis Clamping Force
( Rotational ) 1,100 lbs
Positioning Accuracy
X,Y/ Z -/+ 0.0002”
Repeatability
X,Y/Z -/+ 0.0001”
Pallet Exchange Time
8 Seconds
Positioning Accuracy B Axis
8 Arc-seconds
Repeatability Accuracy B Axis
+/- 2 Arc-seconds
Number of Stations
60 / CAT 40
Tool to Tool ATC Time
2.5 Seconds
Tool Changer Type
Electronic
Maximum Tool Diameter
3.2”
Maximum Tool Length
13.8”
Machine Dimensions
Maximum Operating Dimensions
163.8” x 215.8” x 122.1”
Machine Weight
28,650 lbs
Machine and Accessories Shipping Weight
32,000 lbs
Machine Shipping Dimensions
96.5” x 169.3” x 110.3”
Accessories Shipping Dimensions
96.5” x 150” x 66”
Shipping Dimensions, Tool change side cover
96.5” x 154” x 24”
