| size | 20" x 14" x 18" | 20" x 14" x 18" |
| X Travel | 20" | 508 mm |
| Y Travel | 14" | 355.6 mm |
| Z Travel | 18" | 457.2 mm |
| Table-W | 24" | 609.6 mm |
| Table-L | 48" | 1,219.2 mm |
| # Axis | 3 | 3 |
X‑Axis travel - 20.47 in (519.94 mm)
Y‑Axis travel - 14.96 in (379.98 mm)
Z‑Axis travel - 18.11 in (459.99 mm)
Spindle speed - 8,000 RPM
Spindle taper - BT30
Spindle power - 7.5 hp (5.6 kW)
ATC capacity - 20 tools
Table size 24 in × 48 in (609.6 × 1219.2 mm)
# of axes 3‑axis (with optional 4th‑axis rotary table)
Control Fanuc 150i‑M CNC
Machine dimensions 61 × 105 × 90 in
Machine weight 22,000 lbs
Coolant system Through‑spindle coolant
Probing / accessories
Renishaw probe system
4th-axis rotary table
Fanuc 150i-M CNC control
80 tool holders
through spindle coolant
