Haas ST-30 CNC Lathe (2017)
Have one to sell?
ConditionUsed
1 available
The Haas ST Series high-performance turning centers were designed from the ground up to provide setup flexibility, extreme rigidity, and high thermal stability. This machine offers the best performance for the money – the best value – in its class.
Haas ST-30 CNC Lathe (2017)
Bar Capacity - 3"
Spindle Speed - 3,400 RPM
Spindle Motor - 30HP
X Axis Travel: 12.5"
Z Axis Travel: 26"
Rapid Rate Z Axis: 945 IPM
Turret Tools: 12 Station
Rapid Rate X Axis: 945 IPM
Max Turning Dia: 21"
Max Turning Length: 26"
Max Swing: 31"
Max Thrust X 4100 lbf
Max Thrust Z 5100 lbf
Spindle Nose A2-6
Max Torque 300 ft-lbf
Spindle Bore 3.5"
Coolant Cap 55 gal
Weight: 14,300 LBS
- 12-station turret
- Chip conveyor
