| size | 8" Chuck | 8" Chuck |
| Swing | 21.65" | 549.91 mm |
| Machining Length | 19.68" | 499.87 mm |
| # Axis | 2 | 2 |
| Chuck Size | 8" | 203.2 mm |
| Bar Capacity | 2.2" | 55.88 mm |
| Power | 18 hp | 13.4 kW |
| Max RPM | 4,200 RPM | 4,200 RPM |
| Turning Dia | 10.63" | 270 mm |
| Tailstock | Yes | Yes |
| Live Tooling | No | No |
| Sub Spindle | No | No |
Okuma Crown L1060 2-Axis CNC Lathe
Maximum Swing Over Bed 21.7"
Swing Over Carriage 15.8"
Maximum Turning Diameter 10.6"
Maximum Turning Length 19.7
X Axis Travel 7.3"
Z Axis Travel 20.5"
Rapid Traverse Rate X Axis 590 Ipm
Rapid Traverse Rate Z Axis 787 Ipm
Cutting Feed Range 1 - 400 Ipm
Spindle Bore 2.4"
Maximum Bar Capacity 2.1"
Spindle Speeds 75 - 4,200 Rpm
Spindle Motor 13 Hp
Spindle Nose A2-6
Turret Capacity 12 Stations
Dimensions, Approx. 101" X 72" X 68"
Machine Weight, Approx. 9,500 Lbs
This equipment has been sold. Similar equipment available now is shown below.
