| X Travel | 40" | 1,016 mm |
| Y Travel | 20" | 508 mm |
| Z Travel | 25" | 635 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 24 | 24 |
| Taper | CT 40 | CT 40 |
| Table-W | 18" | 457.2 mm |
| Table-L | 48" | 1,219.2 mm |
- THROUGH-SPINDLE COOLANT (300 PSI)
- VISUAL QUICK CODE PROBING SYSTEM
- SIDE-MOUNT TOOL CHANGER (24 ATC)
- 4TH AXIS DRIVE & WIRING
- 12,000 RPM SPINDLE
- HIGH-INTENSITY LIGHTING
- REMOTE JOG HANDLE
- CHIP AUGER
- INTUITIVE PROGRAMMING SYSTEM (IPS)
- COORDINATE ROTATION & SCALING
- HIGH-SPEED MACHINING
- SPINDLE ORIENTATION
- VISUAL QUICK CODE
- RIGID TAPPING
- MACROS
