Visionwide VF-4000 5 Axis Gantry Type Machining Center
Have one to sell?
ConditionUsed
1 available
One - VisionWide VF-4000 CNC Bridge Mill Double Column Vertical Machining Center
Put in service in 2008
X-axis Travel: 165.35"
Y-axis Travel: 90.55"
Z-axis Travel: 36.22"
Distance Between Columns: 94.49"
Distance Spindle nose to tabletop: 5.9" to 42.12"
Table size: 165.35" x 80.7"
Table load: 28,660 lbs.
Spindle speeds to 8,000 RPM
ATC Stations: 40
Spindle HP: 30
Control: Fanuc 18iMB
Spindle Taper: CAT #50
Machine Weight: 84,480 lbs.
Chip conveyor
Coolant Through Ball Screws
Coolant Through Spindle
4th Axis Prewire
HPCC Data Server, Nurbs, Risc
