Makino S56 Vertical Machining Center (2004)

2005 Makino S56 Machining Center with 40 Taper Spindle

Table:
---------------
Table Size: 1,432 Lbs
Maximum Table Load: 1,100 Lbs

Travels:
---------------
X-Axis Travel: 35.4 inches
Y-Axis Travel: 19.7 inches
Z-Axis Travel: 17.7 inches
Spindle Nose to Table Top: 5,9" - 23.6"

Spindle:
---------------
Spindle Speeds - Maximum: 12,000 RPM Spindle Taper: CT 40 Taper Main Motor (30 min.): 29.5 / 24.2 HP

Tool Changer:
---------------
Tool Changer Positions: 30 ATC
Tool Change Time C-to-C: 4.5 seconds
Max. Tool Length: 11.81 inches
Max. Tool Diameter (with empty adacent pockets): 5.12 inches Max. Tool Weight: 17.6 Lbs

Rapids:
---------------
Rapid Traverse (XY/ Z): 1,575 ipm

General:
---------------
Machine Dimensions (l x w x h)(in.): 101" x 135" x 120"
Machine Weight: 16,500 Lbs
