Hyd-Mech V-18APC Vertical Band Saw (1998)
Have one to sell?
ConditionUsed
1 available
The V-18APC is fast, with its high speed shuttle feed indexing up to 40″ in a single movement. A 2 HP driven hydraulic pump supplies system pressure through 3-position directional valves controlling all vising, head swing, head advance/retract, blade tension, guide arm, and shuttle movement.
Featuring a 18″W x 22″H capacity, 7.5 HP motor, and 1 1/4″ blade, the V-18APC is a reliable choice for all your vertical metal cutting applications.
Hyd-Mech V-18APC Vertical Band Saw (1998)
Rectangular Capacity at 90° 31″ H x 18″ W 787 mm H x 457 mm W
Round Capacity at 90° 17.5″ 444 mm
Blade Dimensions 1.25″ x 16’11″ 34 mm x 4547 mm
Blade Drive 7.5 HP VFD 5.6 kW VFD
Blade Speed 65-385 sfm 19-117 m/min
Coolant Tank Capacity 20 US gal 75 liters
Machine Weight 7500 lbs 3409 kg
Machine Dimensions 168″ W 112″ L 97″ H / 4267 mm W 2844 mm L 2463 mm H
Multi directional hydraulic tilt, hydraulic vices including auto shuttle material feed, chip conveyor, blade
