Hyundai Wia KH1000 4 Axis Horizontal Machining Center (2011)
Have one to sell?
ConditionUsed
1 available
4 Axis, Fanuc 31
Hyundai Wia KH1000 4 Axis Horizontal Machining Center (2011)
Pallet Size
1,000 x 1,000 MM
Pallet Load
3,000 KGS
Pallet Indexing
Full B
Axis Travels - X / Y / Z
2,100 / 1,350 / 1,400 MM
Spindle Taper
CAT50
Pull stud design 45
Maximum tool length and weight: 23.6” 77lbs
Spindle Speeds
8,000 RPM
Spindle Power
26.0 / 22.0 KW
Rapid Traverse Rates - X / Y / Z
20 / 20 / 20 M/MIN
Number of ATC Stations
90
Maximum size of part through the pallet changer door: 59” tall 74.8mm dia
Fanuc 31iB CNC
High Pressure Through Spindle Coolant 1000psi
Macro B
