| Swing | 30.7" | 779.78 mm |
| Machining Length | 29.9" | 759.46 mm |
| Bar Capacity | 3" | 76.2 mm |
| Max RPM | 3,500 RPM | 3,500 RPM |
| Turning Dia | 18.9" | 480.06 mm |
| Tailstock | Yes | Yes |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Control | CNC (Fanuc) | CNC (Fanuc) |
Doosan Puma 2600 2 Axis CNC Lathe (2012)
Bar Capacity: 3"
Chuck Size: 10"
Spindle Speed: 3,500 RPM
Max Turning Length: 29.9"
Max Swing: 30.7"
Spindle Motor: 10 HP
Weight: 17,085 LBS
Turret Tools: 12 Station
Rapid Rate X Axis: 1 IPM
Rapid Rate Z Axis: 1 IPM
X Axis Travel: 10.2"
Z Axis Travel: 32.7"
Fanuc oi CNC Control
Tool Presetter
Right Hand Discharge Turbo 42" Discharge height lift-up type Chip Conveyor
Kitagawa 12" 3-Jaw Power Chuck & Actuator.
145 PSI High Pressure Cooland System
This equipment has been sold. Similar equipment available now is shown below.
