Omax ProtoMAX Abrasive Water Jet (2020)
Have one to sell?
ConditionUsed
1 available
Designed and built alongside the revolutionary OMAX waterjets, The ProtoMAX is a compact, self-contained cutting system ideally suited for prototyping and low-volume cutting of almost any material approximately 1" thick. Bringing all the versatility benefits of large abrasive waterjet cutters together in a sleek and economic package, this machine is ideal for prototyping or as a complement to a larger machine shop.
Omax ProtoMAX Abrasive Water Jet (2020)
WORK ENVELOPE
X-Y Cutting Travel 12.0” x 12.0”
(304 mm x 304 mm)
Z-Axis Travel 1.0” (25 mm)
Table Size 14.5” x 15.25”
(368 mm x 393 mm)
Maximum Supported
Material Load
50 lbs/sq ft
(244 kg/sq m)
Electrical Requirements 230-240 VAC, single phase,
30A, 50/60 Hz
Speed 100 in/min (2,540 mm/min)
Linear Positional Accuracy ±0.005” (±0.127 mm)
Repeatability ±0.003” (±0.076 mm)
Pump Horsepower 5 HP (3.7 kW)
Output Pressure 30,000 psi (2,068 bar)
Orifice and Flow Rate1 0.008” / 0.25 gpm
(0.2 mm / 0.95 lpm)
Pump, software, and bags of garnet.
