| size | 8" Chuck | 8" Chuck |
| Swing | 9" | 228.6 mm |
| Machining Length | 31" | 787.4 mm |
| # Axis | 4 | 4 |
| Chuck Size | 8" | 203.2 mm |
| Bar Capacity | 2.6" | 66.04 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 5,000 RPM | 5,000 RPM |
| Turning Dia | 9.1" | 231.14 mm |
| Tailstock | No | No |
| Live Tooling | Yes | Yes |
| Sub Spindle | Yes | Yes |
| Control | CNC (Fanuc 18i-MB) | CNC (Fanuc 18i-MB) |
| Dimensions | 154 x 82" x 82" | 154 x 82" x 82" |
| Weight | 17,196 LBS | 17,196 LBS |
Bar Capacity: 2.625"
Chuck Size: 8"
Spindle Speed: 5,000 RPM
Spindle Motor: 30 HP
X Axis Travel: 6.5"
X2 Axis Travels: 7.5"
Z Axis Travel: 31.5"
Z2 Axis Travels: 28.3"
Y Axis Travel: 3.9"
A Axis Travel: 30.3"
Rapid Rate Z Axis: 944 IPM
Rapid Rate X Axis: 787 IPM
Max Turning Dia: 9.1"
Max Turning Length: 9.1"
Max Swing: 9.1"
TURRETS:
Turret Configuration (Upper + Lower): 24 + 24 (48 Total Stations)
O.D Tool Size: 0.8" x 0.8"
Maximum I.D. Tool Size: 1.3"
Turret Indexing Time: 0.15 Seconds
Maximum Rotary Tool Speed: 5,000 RPM
SUB & MAIN SPINDLE:
Spindle Speed: 5000 RPM
Spindle Motor (30 min / Cont): 29.5 HP / 20.1 HP
Maximum Spindle Torque: 153.5 Ft-Lbs
Spindle Nose: A2 #6
Spindle Bearing Diameter: 4.3"
Spindle Inner Diameter: 3.0"
C-Axis Indexing: 360° in .001° increments
Fanuc 18i-MB
Chip Conveyor
Tool Presetter
Live Tooling
Sub Spindle
Y Axis
Part Catcher
Part Conveyor
