| size | 31" x 18" x 15" | 31" x 18" x 15" |
| X Travel | 31" | 787.4 mm |
| Y Travel | 18" | 457.2 mm |
| Z Travel | 15" | 381 mm |
| Control | CNC (Fanuc OiMF) | CNC (Fanuc OiMF) |
X Axis: 31.5”
Y Axis: 18.1”
Z Axis: 15.2”
Rotary Table top to spindle nose: 3.78 ~ 19”
Spindle Center to Column: 20”
C axis (Rotating Axis) (degrees): 360°
A axis (Tilting Axis) (degrees): -30° ~ -+120° (150° total)
Table:
Work Area Size: 11.8″ x 17.7″
Height from Floor: 40″
Max. load: 825 lbs.*
Tee Slots (No. x W x D): 4 x .709″ (18mm) x 3.94″
Spindle:
RPM Range: 40 12,000
Spindle Bearing Type: Hybrid Ceramic Bearings
Spindle Draw Bar Type: Collet Style
Retention System: Belleville Disc Spring
Clamping Force: 1,540 lbs
Rotary Parks PAR-170KRC Full 5-axis built-in trunnion rotary table, dual interior chip augers, chip conveyor, probe software installed, probe software installed, manual pulse generator, misc. tooling
This equipment has been sold. Similar equipment available now is shown below.
