30" X 18" X 16" Monarch VMC-45 Vertical Machining Center (1998)
Have one to sell?
ConditionUsed
1 available
50 Taper, 6000 RPM, Fanuc 16M
30" X 18" X 16" Monarch VMC-45 Vertical Machining Center
Table Size: 42" x 18"
X-Axis Travel: 30"
Y-Axis Travel: 18"
Z-Axis Travel: 24"
Traverse Rate (X,Y,Z): 600 ipm
Feedrate max.: 300 ipm
Ballscrews: 2" dia.
Table Load: 3,000 lbs
Tool storage capacity: #50 Taper 26 tools
Spindle Speed: 30-6,000 RPM
Spindle Nose Taper, ANSI: #50
Approximate Machine Weight: 16,000 Lbs
Equipped With
GE Fanuc 16-M
Chip Conveyor
Remote Jog Handwheel / Manual Pulse Generator
Loading Charge of 500
