24.8" X 24.8" Toyoda FH-630S 3-Axis CNC Horizontal Machining Center (2004)

Toyoda FH-630S 3 Axis CNC Horizontal Machining Center
**** 16000 Cut Hours / Aluminum and Steel ***
Number of Pallets: 2
Pallet Size: 24.8" X 24.8"
Pallet Workload Capacity:
X-Axis Travel: 39.37"
Y-Axis Travel: 31.46"
Z-Axis Travel: 33.46"
B-Axis (Rotary 1 degree
Spindle Nose to Center of Rotary Table: 6.9 - 36.4 in (175 - 925 mm)
Spindle Speed: 15000 RPM
Spindle Taper: CT 50
Tool Capacity: 40 ATC
Spindle Motor: 30 HP
Equipped with:
Fanuc 30I-A CNC Control
Through Spindle Coolant 1000 PSI
Chip Conveyor Rear Discharge
Linear Ways
40 ATC
Daiken Chiller
RS232 Flash Drive
Utilization: Aluminum and Steel
