OKUMA Crown 762S SB
Have one to sell?
ConditionUsed
1 available
10" Chuck, Barfeed
Okuma Model 762S SB 2-Axis CNC Lathe
Swing Over Bed: 21.65"
Swing Over Cross Slide: 15.75"
Maximum Turning Diameter: 10.63"
Max Turning Length: 19.68"
Spindle Speeds: 75-4200 RPM
Spindle Motor: 18/10 HP
Spindle Nose: A2-6
Spindle Bore: 2.44"
Max Bar Size: 2.0"
Turret Stations: 12
Rapid Travels: X and Z: 590 IPM
Tailstock Spindle Taper/Travel: MT #5 / 4.72"
Tailstock Spindle Diameter: 3.54"
Tailstock Body Travel: 18"
Dimensions: 104" x69.4" x 70" high
Approximate Weight: 10,000 Lbs
Electrics: 220V 3 Phase
Okuma OSP CNC Control
SMW SpaceSaver 2000 Barfeed
10" Kitagawa Hydraulic Chuck
S30 Collet Chuck
Chip Conveyor
Misc. collets, boring tool blocks, spindle liners
